Frame Simulator
The frame simulator uses a VM VirtualBox Virtual Machine to run the Carbonite software application. The simulator cannot pass video, but can be used to create offline switcher sets, prepare for upcoming shows, or training.
To Run the Frame Simulator
Run the sim to obtain the IP address that you will point DashBoard to.

To Run the Frame Simulator

Run the sim to obtain the IP address that you will point DashBoard to.

Launch VM VirtualBox.
Click on the in the Oracle VM VirtualBox Manager.
Click Start to start the Carbonite SIM.

A separate window will open up as the simulator starts. Wait for the application to finish.
When the simulator is up and running the Ubuntu® version is shown at the top with the IP address of the simulated Carbonite frame (in the example below it is [192.168.1.23]).
